Single Girder Gantry Crane

Single Girder Gantry Cranes for outdoor and indoor material handling where overhead runway structures are unavailable. Lightweight A-frame construction on floor-mounted rails delivers cost-effective lifting with reliable, wind-rated performance.

Capacity	1 – 15 Ton
Span	Up to 30 m
Lift Height	Up to 50 m
Speed	Selected according to client application
Duty Class	M3, M5, M7, M8
Motors	Squirrel Cage / Slip Ring
Legs	Fabricated A-Frame
Travel	Rail Mounted
Wheels	Double-flanged forged, machined tread
Cantilever	One Side / Both Side
Duty	Outdoor Wind Rated
Control	Pendant / Radio Remote
Electricals	Weatherproof IP-rated panels
Paint	Epoxy Primer + Epoxy Finish / PU Topcoat
Standards	IS 3177 · IS 807 · IS 875

Get Quote in 24 Hrs WhatsApp Call Now

Technical Details

Built To Standard, Tested Beyond It

IS 875 Wind-Rated StructureDesigned for parked and in-service wind loads.

Braced A-Frame LegsRigid fabricated legs on floor-level rails.

No Building RequiredFull lifting coverage without crane columns.

Storm Clamps & Anchor PinsPositive anchorage in parked condition.

Optional Cantilever EndsHook reach beyond rails for truck lanes.

Outdoor-Grade PU FinishEpoxy primer system built for weather.

Laser-Aligned Rail Setting±2 mm rail tolerance over the runway.

125% SWL Load TestedCertified proof test before dispatch.

The ETC Quality Promise

125% SWL load test before every dispatch, documented & stamped
IS:2062 tested plates with mill certificates on file
IS:3177 / IS:4137 / FEM 1.001 compliant design calculations
Stress-relieved fabrication at critical welded joints
ISO 9001:2015 certified manufacturing process

About This Product

Engineered For Indian Industry

Single Girder Gantry Cranes bring overhead lifting to yards, loading bays and sheds that have no crane-ready structure: the bridge rides on two braced A-frame legs travelling on floor-mounted rails, so the full span between rails becomes productive lifting area. The lightweight single-girder configuration keeps civil and equipment costs low.

Structures are wind-load checked to IS 875 for outdoor service with storm clamps and parking anchors as standard; electricals are housed in weatherproof IP-rated panels with festoon cable running in galvanised C-track, and UV-stable PU coating over epoxy primer protects the steel year-round. The crane follows IS 3177 / IS 807 design practice with a 125% SWL proof test before dispatch, and optional cantilever extensions carry the hook beyond the rails for loading trucks alongside the runway.

Outdoor yard lifting?

Tell us your yard length, span and heaviest lift — we design rails, foundations and crane as one package.

Key Features

Zero building dependence — runs entirely on ground rails
Economical A-frame design — light foundations, low civil cost
Cantilever options — one or both sides for truck loading
Wind-rated for outdoors — IS 875 checked, storm anchored
Weather-sealed electricals — IP-rated panels and fittings
Pan-India erection — rails, alignment and commissioning

Applications

Where This Machine Earns Its Keep

Warehousing & Logistics

Fast, safe loading and unloading across storage bays and dispatch yards.

Infrastructure Projects

Precast segment and girder erection at bridge, metro and dam sites.

Fabrication Workshops

Positioning heavy weldments and machined assemblies with precise inching control.

Agro & Pump Industry

Handling castings, motors and pump assemblies through test beds.

General Engineering

Workshop lifting for machine shops, assembly lines and test beds.

Solar & Renewables

Module-line gantries and structure-yard cranes for renewable projects.

Safety First

Safety Features As Standard

Overload Limiter

Electronic load cell cuts hoisting the moment load exceeds rated SWL.

⬆ Upper/Lower Limit Switches

Rotary geared and counterweight limits stop hook over-travel in both directions.

Motion Warning Hooter

Audible alarm and flasher warn floor staff during LT/CT travel.

Fail-Safe DC Brakes

Electromagnetic brakes engage automatically on power failure — load holds instantly.

Pendant + Radio Remote

IP-65 push-button pendant with optional wireless remote and emergency stop.

Panel Protection

SPP, overload relays and single-phase preventers protect motors and VFDs.

FAQ

Questions Buyers Ask Us

ETC single girder gantries are standard from 1 to 15 Ton with spans up to 30 metres — the economical choice for yards and bays. Heavier requirements move to our double girder gantry range.

Yes — the structure is wind-load designed per IS 875 for your region, with storm clamps and parking pins holding the crane positively when idle. Optional anemometer interlocks can cut travel above set wind speeds.

The crane runs on CR rails grouted onto a simple ground beam — far cheaper than building columns and gantry girders. We supply the rail, clamps and bolt-setting drawings together with static and dynamic wheel-load data, so your civil contractor designs the ground beam once and correctly.

IS 3177 and IS 807 govern the crane design, IS 875 the wind loading, and every machine is proof-tested at 125% SWL with a stamped certificate before it leaves our Ahmedabad works.

Yes — cantilever extensions on one or both sides are a standard option, letting the hook travel beyond the rail line to serve truck lanes or storage strips alongside the runway.

Our teams erect the legs and bridge, lay and laser-align the rails to ±2 mm, wire the power feed and commission all motions — typically 3–5 days for a standard span, handed over after an on-site load trial.

A 12-month warranty backed by AMC options, spares stock for all wear parts, periodic statutory load testing and 24×7 breakdown support anywhere in India.

Standard single girder gantries ship in 5–7 weeks from drawing approval; rail material can be dispatched early so your civil work proceeds in parallel with fabrication.
